8‑Way C13 PDU Aluminum

The 8‑Way C13 PDU Aluminum is a professional‑grade power distribution unit engineered for data centers, network cabinets, server rooms, and high‑density rack environments. Built with a rugged aluminum housing for enhanced durability and heat dissipation, this PDU delivers reliable and organized power to eight IEC C13 outlets. With flexible mounting options and integrated protections, it ensures efficient power management for servers, switches, storage devices, and other critical IT equipment.

Product Features

Precision Machined Aluminum Housing

Constructed with a strong yet lightweight aluminum body, the PDU housing offers improved heat resistance, durability, and long service life in demanding environments.

Eight IEC C13 Outlets

Equipped with eight IEC C13 sockets to support multiple devices commonly used in rack‑mount systems and network installations.

Fused Input Protection

Includes a built‑in fused input to protect connected equipment from overcurrent and help maintain safe operation.

Rack‑Mount Compatible Design

Designed to fit standard 19‑inch rack systems, the PDU can be installed horizontally for streamlined power distribution and cable management.

Surge and Electrical Protection

Integrated surge protection safeguards sensitive electronic components from voltage spikes and electrical disturbances.

Centralized Power Control

Featuring a clearly labeled On/Off switch to control power delivery to all outlets easily, improving operational convenience.

Product Specifications

• Outlet type: 8 × IEC C13
• Input connection: IEC C14 or hardwired option
• Housing material: Anodized aluminum
• Rated voltage: 100–240V AC
• Rated current: 10A or 16A configurations available
• Cable length: Standard 1.8 meters (custom lengths available)
• Mounting option: Horizontal 19‑inch rack mount compatible
• Safety certifications: CE, RoHS compliant
• Operating temperature range: –10°C to 50°C
• Dimensions: 430mm × 44mm × 40mm
• Weight: 1.3 kg
