Kodak S2085f 85 PPM Gigabit LAN USB 3.2 Gen Document Scanner

The Kodak S2085f 85 PPM Document Scanner is a high-volume A4 document scanner designed for organizations that need fast document capture, flexible connectivity and practical handling of different document types. It scans at up to 85 pages per minute or 170 images per minute, has a 300-sheet automatic document feeder (ADF), an integrated A4 flatbed for books, fragile documents and other exception media, and supports both Gigabit Ethernet and USB 3.2 Gen 1×1 connectivity. Its 3.5-inch colour touchscreen, Smart Touch technology, onboard image processing and document-feeding features make it suitable for departmental document scanning environments where scanning speed, document handling and network access are important.

Product Features

85 PPM High-Speed Document Scanning

The Kodak S2085f scans at up to 85 pages per minute and 170 images per minute. Actual throughput can vary depending on the driver application, operating system, computer configuration and selected image-processing features.

300-Sheet Automatic Document Feeder

The scanner has an automatic document feeder with a capacity of up to 300 sheets of 80 g/m² paper. This allows users to load a larger batch of documents for scanning rather than feeding individual sheets manually.

Integrated A4 Flatbed

The integrated A4 flatbed provides an alternative scanning path for documents that are not suitable for the automatic feeder. It can be used for books, photos, fragile documents and other exception media.

Gigabit Ethernet Network Connectivity

The S2085f includes 10/100/1000 Ethernet, allowing it to connect to a network. Kodak Alaris states that its built-in Gigabit Ethernet can allow multiple users to share the scanner within a department when configured for network use.

USB 3.2 Gen 1×1 Connectivity

For direct computer connection, the scanner supports USB 3.2 Gen 1×1, with USB 2.0 compatibility. Kodak Alaris identifies USB 3.2 Gen 1×1 as the 5 Gbps USB interface generation.

Smart Touch Technology

Smart Touch technology allows users to create scanning workflows that can be started from the scanner’s interface. This can simplify repetitive scanning tasks and document routing.

Onboard Image Processing

The S2085f includes onboard image processing, which can reduce the image-processing workload placed on the connected computer. The scanner can also operate with host-based processing depending on the selected workflow.

Intelligent Document Protection and Multifeed Detection

The scanner uses intelligent document protection and ultrasonic multifeed detection to monitor documents as they pass through the feeder. The document protection function is designed to stop scanning when abnormalities associated with potential document problems are detected.

Controlled Stacking for Mixed Document Batches

Controlled stacking helps manage documents as they exit the scanner. The output rollers adjust their speed to provide greater control over documents entering the output tray.

3.5-Inch Colour Touchscreen

The scanner features a 3.5-inch graphical colour touchscreen LCD together with physical operator control buttons. The interface can be used to access scanning functions and configured workflows.

Dual Light Illumination

Kodak Alaris uses dual RGB LED illumination in the S2085f’s scanning technology. The manufacturer’s image-processing system includes functions such as background smoothing, automatic orientation, deskew, blank-page removal and other image enhancement options.

FADGI 2023 Compliance

The Kodak S2085f is listed by Kodak Alaris as compliant with FADGI 2023: Documents (Unbound): Modern Textual Records, with validation using Golden Thread NXT version 10.4. This makes the documented compliance relevant for organizations working with digitization requirements where the applicable FADGI standard is required.

Multiple Document Output Formats

The S2085f supports output formats including PDF, searchable PDF, JPEG, PNG, TIFF, BMP and RTF, while Microsoft Word and Excel output is available through bundled applications.

Product Specifications

• Brand: Kodak Alaris
• Model: S2085f
• Product type: A4 document scanner
• Scanning speed: Up to 85 ppm / 170 ipm
• Feeder capacity: Up to 300 sheets of 80 g/m² paper
• Connectivity: 10/100/1000 Ethernet, USB 3.2 Gen 1×1, USB 2.0 compatible
• Maximum optical resolution: 600 dpi
• Image output resolution: Up to 1200 dpi
• Maximum ADF document size: 216 mm x 4.06 m
• Maximum flatbed document size: 220.7 mm x 304.8 mm
• Minimum document size: 63.5 mm x 71.1 mm
• Minimum hand-fed document size: 50 mm x 50 mm using the hand-feeding and straight paper path
• Paper thickness and weight: 34–433 g/m²
• Paper weight for rear exit: Over 200 g/m²
• Recommended daily volume: Up to 20,000 pages per day
• Operator control panel: 3.5-inch graphical colour touchscreen LCD with operator control buttons
• Scanning technology: Dual RGB LED illumination CIS (CMOS)
• Grayscale output: 8-bit / 256 levels
• Colour output: 24-bit
• Colour capture: 48-bit
• Network protocols: DHCP or static IP, TCP/IP
• Supported operating systems: Windows 10, Windows 11, selected Windows Server versions, Ubuntu, SUSE Linux Enterprise Desktop and other specified Linux distributions
• Dimensions: 457.2 mm W x 370.84 mm D x 254 mm H
• Weight: 17 kg
• Electrical requirements: 100–240 V, 50–60 Hz
• Power consumption: Less than 0.3 W standby, less than 4.7 W sleep, less than 70 W running
• Maximum optical resolution: 600 dpi
• File formats: BMP, JPEG, TIFF, PDF, searchable PDF, PNG and RTF; Microsoft Word and Excel available through bundled applications
• Bundled software: KODAK Capture Pro Software Limited Edition and Smart Touch
• Drivers: TWAIN, ISIS and WIA; Linux TWAIN/SANE drivers are also specified
• Barcode reading: Codabar, Code 128, Code 3 of 9, EAN-13, EAN-8, Interleaved 2 of 5, PDF417, QR, UPC-A and UPC-E
• Operating temperature: 10–35 °C
• Operating humidity: 15–80% RH

Who Is the Kodak S2085f Suitable For?

The Kodak S2085f is appropriate for organizations that need an A4 scanner with a combination of high scanning throughput, large ADF capacity, network connectivity and flatbed scanning.

It can be considered for offices, departments and document-intensive environments where users need to process batches of paper documents and may also need to scan books, photographs, fragile documents or other materials that are better suited to a flatbed.

The 10/100/1000 Ethernet connection also makes the S2085f relevant where network-based scanning is required rather than limiting the scanner to a single direct USB connection.

Why Choose the Kodak S2085f?

The Kodak S2085f brings together several features that matter when document scanning becomes a regular operational requirement: 85 ppm scanning, a 300-sheet feeder, integrated A4 flatbed scanning, Gigabit Ethernet, USB 3.2 Gen 1×1, onboard image processing and document protection features.

Rather than relying on speed alone, the S2085f provides multiple ways to handle documents and connect the scanner to an organization’s workflow.

Contact Zeneric Networks Limited for the Kodak S2085f 85 PPM Document Scanner, current pricing, availability and purchasing information.
