Siemon Cat 6A UTP Ethernet Cable 305m Roll
The Siemon Cat 6A UTP Ethernet Cable 305m Roll is a premium-grade structured cabling solution engineered for high-speed and high-bandwidth network installations in enterprise, data center, and commercial environments. Constructed with 23 AWG solid copper conductors and individually twisted pairs, this cable supports bandwidths up to 500 MHz and 10 Gigabit Ethernet speeds. Its low-smoke, zero-halogen (LSZH) jacket enhances safety for indoor installations, while the superior shielding and design minimize crosstalk and electromagnetic interference. Ideal for backbone cabling, PoE+ devices, IP surveillance systems, and high-performance LAN networks, it delivers consistent reliability and future-proof performance.
Product Features
Cat 6A High-Bandwidth Performance
Supports 10 Gigabit Ethernet speeds with bandwidth up to 500 MHz, ensuring high-speed data transmission for demanding applications.
Solid Copper Conductors
Built with 23 AWG solid bare copper for superior conductivity, reduced signal attenuation, and long-term network reliability.
Individually Twisted Pairs
Four tightly twisted pairs reduce crosstalk and electromagnetic interference, maintaining signal integrity for high-performance networks.
Durable Low-Smoke Zero-Halogen Jacket
LSZH jacket minimizes toxic emissions during fire and provides protection against mechanical stress in indoor structured cabling systems.
Reverse Sequential Marking
Includes sequential numbering on the jacket for accurate measurement and easier cable management during installation.
PoE and PoE+ Compatibility
Supports powering devices such as IP cameras, VoIP phones, and wireless access points via Power over Ethernet applications.
Enterprise-Grade Structured Cabling
Designed for offices, data centers, campuses, and other commercial environments where high reliability and future-proof infrastructure are required.
Product Specifications
- Cable category: Cat 6A UTP (Unshielded Twisted Pair)
- Conductor material: 23 AWG solid bare copper
- Number of conductors: 8
- Pair configuration: 4 individually twisted pairs
- Bandwidth: Up to 500 MHz
- Maximum data speed: 10 Gbps
- Maximum channel length: 100 meters
- Cable length: 305 meters roll
- Jacket material: Low-smoke zero-halogen (LSZH) or lead-free PVC
- Marking: Reverse sequential numbering for installation management
- Standards compliance: ISO/IEC 11801, ANSI/TIA‑568‑C.2, UL verified, RoHS compliant
- Installation environment: Indoor use
- Application: High-speed LAN, backbone infrastructure, IP surveillance, PoE and PoE+ devices, enterprise networks
